CURR MIN AVG MAX
27.9 89.7 323.6 Solar collector A
12.8 26.4 49.1 Outside sensor
21.4 40.8 44.3 Towel dryer inlet
22.1 23.8 25.8 Floor heating inlet
20.2 21.8 23.9 Floor heating outlet
23.4 25.2 27.3 2 tank middle. House heating inlet.
18.6 19.2 20.0 2 tank top.
13.1 14.4 15.6 1 tank bottom.
14.5 15.9 17.3 1 tank middle.
17.2 18.5 19.8 1 tank top.
21.0 22.6 24.5 Return to furnace.
16.4 50.1 55.5 Boiler top.
16.3 48.4 54.6 Boiler middle.
11.5 15.1 18.6 Boiler bottom.
19.8 21.5 24.4 Return from ground collectors.
18.8 20.5 22.4 Bufer tank bottom.
20.6 22.7 25.8 Bufer tank top.
15.6 16.4 17.3 2 tank bottom.
16.0 16.8 17.6 2 tank middle.
Floor heating pump.
Floor heating motorised valve open.
Floor heating motorised valve close.
Towel dryer open.
Towel dryer close.
Water recirculation line swich pos A (Boiler).
Water recirculation line swich pos B (Heat exchanger in tank).
Ground collectors pumps.
Towel dryer pump.
DHW recirculation pump.
Electromagnetic valves TV6, TV7 (Normal closed)
Electromagnetic valves TV8, TV9 (Normal open)
Electrotermic valves
Lazar Smartfire 11 pellet boiler control
Solar collector pump control 0-10V
